Dashboard Ops Center

The Dashboard Ops Center is ValkyrAI's comprehensive operations monitoring solution, providing real-time insights into system health, API object statistics, and workflow performance. Built with a world-class interface matching the CRM design standards, it consolidates all operational monitoring into a unified, elegant dashboard.

Features​

🎯 Real-Time API Object Statistics​

  • Accurate Counts: Live statistics for all API entities (Workflows, Tasks, Principals, etc.)
  • User Preferences: Customizable monitoring - select which objects to watch
  • Auto-Refresh: Updates every 30 seconds with manual refresh capability
  • Error Handling: Clear error reporting and recovery mechanisms

📊 Multi-View Dashboard​

  • Overview: Object statistics and system health at a glance
  • Workflow Metrics: Detailed workflow performance and execution statistics
  • System Operations: Actuator-based system monitoring and health checks

🎨 Professional Design​

  • LCARS-Style Interface: Consistent with ValkyrAI design language
  • Responsive Layout: 3D workflow viewer on right, controls and data on left
  • Interactive Elements: Configurable widgets and real-time updates
  • Visual Indicators: Color-coded status and error reporting

Architecture​

Backend Components​

Statistics Controller​

Location: valkyrai/src/main/java/com/valkyrlabs/valkyrai/controller/StatisticsController.java

Provides REST endpoints for table statistics:

  • GET /v1/statistics/tables - All table statistics
  • GET /v1/statistics/tables/{entityName} - Specific entity statistics
  • GET /v1/statistics/summary - Summary statistics

Enhanced Repository Template​

Location: valkyrai/src/main/resources/templates/JavaSpring/repository.mustache

All generated repositories now include:

  • countAll{EntityName}() - Get total record count
  • getTableSize() - Default table size implementation
  • getTableName() - Table name for reporting
  • getEntityName() - Entity name for statistics

Frontend Components​

ObjectStatsPanel​

Location: web/typescript/valkyr_labs_com/src/components/ObjectStatsPanel/index.tsx

Features:

  • Real-time API statistics fetching
  • User preference management with localStorage persistence
  • Configurable entity monitoring
  • Error handling and retry logic
  • Modal configuration interface

DashboardTab​

Location: web/typescript/valkyr_labs_com/src/components/Dashboard/tabs/DashboardTab.tsx

Consolidated dashboard featuring:

  • Tabbed navigation (Overview, Workflow Metrics, System Operations)
  • 3D workflow viewer integration
  • Professional LCARS styling
  • Responsive multi-column layout

Usage​

Accessing the Dashboard​

Navigate to /dashboard-ops in your ValkyrAI application to access the Dashboard Ops Center.

Configuring Monitored Objects​

  1. Click the gear (⚙️) icon in the API Object Statistics panel
  2. Select/deselect entities you want to monitor
  3. Changes are automatically saved to localStorage
  4. Preferences persist across browser sessions
  • Overview Tab: Default view showing object statistics and system health
  • Workflow Metrics Tab: Detailed workflow performance data
  • System Operations Tab: Actuator-based system monitoring

Implementation Details​

User Preferences Storage​

type UserPreferences = {
  watchedEntities: string[];
  lastUpdated: string;
};

const STORAGE_KEY = "dashboardOps.objectStats.preferences";

Preferences are stored in localStorage and include:

  • List of entities to monitor
  • Last update timestamp for tracking changes

API Integration​

The dashboard integrates with multiple backend services:

  • Statistics API: Real-time object counts
  • Actuator Endpoints: System health and metrics
  • Workflow Services: Performance and execution data

Security​

All endpoints are protected with Spring Security:

@PreAuthorize("hasRole('ROLE_USER') or hasRole('ROLE_ADMIN')")

Configuration​

Backend Configuration​

Enable statistics collection by ensuring the StatisticsController is included in component scanning:

@ComponentScan(basePackages = {"com.valkyrlabs.valkyrai.controller"})

Frontend Configuration​

The dashboard automatically detects the API base URL from environment variables:

  • VITE_basePath (Vite)
  • REACT_APP_BASE_PATH (Create React App)
  • Auto-detection based on current location

Performance Considerations​

Database Impact​

  • Statistics queries use efficient COUNT operations
  • Repository-level caching can be implemented for frequently accessed statistics
  • Consider database indexing for large datasets

Frontend Optimization​

  • 30-second auto-refresh interval balances freshness with performance
  • Component-level state management reduces unnecessary re-renders
  • Lazy loading of configuration modal improves initial load time

Troubleshooting​

Statistics Not Loading​

  1. Verify backend is running and accessible
  2. Check browser console for API errors
  3. Ensure user has appropriate permissions
  4. Verify statistics endpoints are responding

Configuration Not Persisting​

  1. Check browser localStorage is enabled
  2. Verify no browser extensions are blocking storage
  3. Clear localStorage and reconfigure if corrupted

Performance Issues​

  1. Reduce refresh frequency if needed
  2. Limit number of monitored entities
  3. Check database performance for COUNT queries

Future Enhancements​

Planned Features​

  • Custom Refresh Intervals: User-configurable update frequencies
  • Historical Data: Trend analysis and historical statistics
  • Alerting: Threshold-based notifications and alerts
  • Export Capabilities: CSV/JSON data export functionality
  • Advanced Filtering: Date range and condition-based filtering

Integration Opportunities​

  • Grafana Integration: Advanced charting and visualization
  • Prometheus Metrics: Time-series data collection
  • Slack/Teams Notifications: Real-time alerting integration

API Reference​

GET /v1/statistics/tables​

Returns array of table statistics:

[
  {
    "entityName": "Workflow",
    "tableName": "workflow",
    "count": 42,
    "error": null
  }
]

GET /v1/statistics/summary​

Returns summary statistics:

{
  "totalEntities": 8,
  "totalRecords": 1234,
  "errors": 0,
  "timestamp": "2025-09-15T11:45:26.000Z"
}
